Description
Sub-Zero PCIe Fansink, 50 x 64 x 10.5mm, 12V
When ordering without pushpins Radian recommends using a 3M8815 full coverage thermal interface.
| Part | Type | Material | Width (mm) | Length (mm) | Height (mm) | Theta SA (°C/W) | Voltage (V) |
|---|---|---|---|---|---|---|---|
| SZ12L | Pushpin | Aluminum | 50 | 63.37 | 10.5 | 1.85 | 12V |
A PCIe Fansink is specifically designed for a PCI Express (Peripheral Component Interconnect Express) card. As a PCIe card has a height restriction of 14.48mm this means that fin height is fairly limited for the PCIe heatsink, especially when considering that a typical BGA chip height is around 3mm including solder balls.
